TSSCO DLS-15/07

Description

Product Specification:

Height Accuracy:

1. Standard deviation for 1km of – 1.5mm

2. Double leveling – 2.0mm (optical measure)

Distance:

1. Distance Accuracy – D<10m: 10mm, D>10m: D*0.001

2. Distance Range – 2-110m

Minimum Display:

1. Height Measurement – 0.1mm/1mm

2. Distance Measurement – 0.01m/0.1m

Measure Performance:

1. Measuring Time – 3s

Telescope:

1. Magnification – 32X

2. Resolving Power – 3”

3. Field of View – 1°30’

4. Multiple Constant – 100

5. Additive Constant – 0

Compensator:

1. Type – Magnetic-damped

2. Range – 12’

3. Accuracy – 0.5“/1‘

Data Storage:

1. Internal Storage –  16MB (>100,000 points)

2. Point Name –  Increasing/decreasing/customized

3. Connection – Mini-USB

4. External Storage – Unavailable

Level:

1. Circular Vial – 8’/2mm

Display & Keyboard:

1. Display – 128*32dpi LCD

2. Keyboard – 16 keys + 1 power/ trigger button

Power Supply:

1. Battery – Rechargeable Li-on Battery, 2000mAh

2. Operating Time – 20h

General:

1. Working Temperature – -20°C – 50°C

2. Dimensions – 230*150*210mm

3. Weight – 2.5kg

4. Water & Dust Proof – IP54
